BIZON X7500

• Artificial Intelligence
• Big Data Analytics
• High-performance Computing
• Research Lab/National Lab
• Astrophysics, Business Intelligence

Dual CPU server board.

• AMD EPYC 9004/9005 series processors LGA 6096 (Socket SP5).
• System on Chip (SoC).

• AMD EPYC 9004/9005 series processor family
• Dual processors, 5nm
• Up to 192-core, 384 threads per processor
• cTDP up to 500W

• Up to 3072 GB DDR5 5600 MHz ECC Buffered
• 24 x DIMM slots
• DDR5 memory supported only
• 12-Channel memory per processor architecture
• RDIMM modules up to 128GB supported
• 3DS RDIMM modules up to 512GB supported

NOTE: actual RAM clock speed depends on the CPU specifications and may vary.

• 6x MCIO (PCIe5.0 / CXL2.0 x8) (CPU0)
• 2x MCIO (PCIe5.0 / CXL2.0 x8 or 8 SATA 6Gb/s) (CPU0)
• 2x MCIO (PCIe5.0 x8 or 8 SATA 6Gb/s) (CPU0)
• 6x MCIO (PCIe5.0 / CXL2.0 x8) (CPU1)
• 2x MCIO (PCIe5.0 / CXL2.0 x8 or 8 SATA 6Gb/s) (CPU1)
• 2x MCIO (PCIe5.0 x8) (CPU1)

• 4 x 2.5" U.2/SATA Front Hot-swap Storage Bays
• 1x M.2 (PCIe3.0 x4 or SATA 6Gb/s, supports 22110/2280 form factor) (CPU0)
• 1x M.2 (PCIe3.0 x4 or SATA 6Gb/s, supports 22110/2280 form factor) (CPU1)

• 2 x 1GbE LAN (Intel i350)
• 1 x 10/100/1000 management LAN (Dedicated IPMI, Realtek RTL8211F)
• 10 Gigabit Dual Port Ethernet (2x RJ45) (optional)
• 25 Gigabit Dual Port Ethernet (2x SFP28) (optional)
• 100 Gbps Dual Port InfiniBand EDR (Mellanox ConnectX VPI Adapter; 1x QSFP) (optional)
• 200 Gbps Dual Port InfiniBand HDR (Mellanox ConnectX-6 VPI Adapter; 2x QSFP) (optional)
• 400 Gbps Single Port InfiniBand NDR (Mellanox ConnectX-7 VPI Adapter; 1x OSFP) (optional)

• Integrated in Aspeed AST2600
• 2D Video Graphic Adapter with PCIe bus interface
• 1920x1200@60Hz 32bpp, DDR4 SDRAM

Up to 8 Nvidia graphics cards.

Available options:

• Nvidia RTX PRO 4000 Blackwell 24Gb (4 DP)
• Nvidia RTX PRO 4500 Blackwell 32Gb (4 DP)
• Nvidia RTX PRO 5000 Blackwell 48Gb (4 DP)
• Nvidia RTX PRO 6000 Blackwell Max-Q 96Gb (300W) (4 DP)
• Nvidia RTX PRO 6000 Blackwell 96Gb (600W) (4 DP)

Display Support (all cards):
Maximum Digital Resolution: 7680x4320 @60Hz
Multi Monitor Support: 4

N/A

• 4 x Type-A (USB 3.2 Gen1)
• 2 x RJ45
• 1 x MLAN
• 1 x VGA (DB15)
• 1 x UID button w/ LED
• 1 x PWR button
• 1 x RST button
• 1 x NMI button
• 1 x HDD LED
• 1 x SYS LED

1 x TPM header with SPI interface

• 4+1 2000W 80 PLUS Titanium redundant power supply
• Rating: 110-240 Vac, 16.0A(x5), 50-60 Hz

NOTE: X7500W comes with 5 x 2000W Redundant (4+1) power supplies. Total 5 power supplies (4 main + 1 backup).
That means that maximum output power is 8000W (4 x 2000W) with 2000W (1 x 2000W) for backup power supplies.
If one power suppliy will fail, the backup power supply starts running to keep the computer powered up.
The switch between the power supplies is seamless, so as not to interrupt the normal use of the computer.

Power cord requirements:
C19 (PSU) to 5-15P (regular US home outlet).
C19 (PSU) to C20 (plug) (PDU).

110-240V:
If you have a standard 20 A / 120V US outlet, you can connect one power supply to one dedicated power circuit (each outlet should have its dedicated circuit). In total, you need five (5) 20 A /120V outlets with a dedicated circuit.

Actual power consumption is not the same as maximum power supply power. Power supply power means how much watts you can get from the power supply and your actual power consumption should not be higher than max power supply power. Actual power consumption depends on your configuration (graphics card and CPU).

Power consumption example:
X7500 with 8 x Nvidia RTX PRO 6000 + 2 x AMD EPYC 9124 CPUs = 5700-6000W (100% load for all the GPUs and CPUs).

Information for reference only. Consult your electrician for more details.

The system power supply is universal and will work worldwide. Compatible with 110v – 240v (50-60 Hz).

BizonOS and BizonOS Control Panel.
BizonOS includes a user-friendly, web-based control panel with everything one needs, all organized into one convenient location.

BizonOS features:

• Remote access from anywhere (SSH/VNC)
• Virtual machines
• GPU sharing
• Containers
• One-click software updates
• Jupyter notebooks
• GPU/System monitoring
• accounts, and permissions

• BIZON Z–Stack (Ubuntu 24.04 with preinstalled deep learning frameworks).
• Rocky Linux 9 (optional).
• Windows 11 Pro (optional).
• Microsoft Windows Server 2022 Standard (optional).
• No operating system (optional).


• Microsoft Windows Server 2019.
• Microsoft Windows Server 2022.
• Microsoft Windows Server 2025.
• Red Hat Enterprise Linux 8.x (x64) or later
• Red Hat Enterprise Linux 9.x (x64) or later
• Ubuntu 22.04 LTS (x64) or later
• Ubuntu 24.04 LTS (x64) or later

• Operating temperature: 50° to 95° F (10° to 35° C)
• Operating humidity: 8%-80% (non-condensing)
• Non-operating temperature: -40° to 140° F (-40°C to 60°C)
• Non-operating humidity: 20%-90% (non-condensing)

8 x NVIDIA RTX PRO 6000:

Idle: 60 dB
Max Load (stress test): 80 dB

Measured from 6 ft / 1.8 m distance.

• Desktop or Rackmountable; vertical or horizontal placement
• Height: 12.21 inches (31.2 cm)
• Width: 17.32 inches (44.7 cm)
• Depth: 35.43 inches (90.0 cm)

Shipping Package

• Height: 16.93 inches (43.5 cm)
• Width: 22.83 inches (58.0 cm)
• Length: 42.13 inches (107.5 cm)
• Weight: 180.8 lbs (82.4 kg) (shipped on pallet)

• Bizon X7500
• 1 x Rail kit
• 5 x power cords (USA)
• User manual
• Benchmark report

bizon-x7500-0925
